The Morrow MB-565 twins with the Morrow MB-6 receiver and is the follow up to the Morrow MB-560. The MB-6 / MB-565 combination forms a very compact communication set, rather special for its time. Morrows are rare these days.

Requires an external power supply. Recommended power supplies include the Morrow RVP-260B and TV-600A or the combined RTV-630.

General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
Continuous
Memories
None

Transmitter

TX-range
80-10 m
Modulations
-
RF-output
25 W

Connections

Antenna
SO-239
Impedance
52-70Ω
Other
-

Electrical

Power requirements
External PSU (6 or 12 V DC / 67.5 V DC, 275 V DC / 300~600 V DC)
Current drain RX
-
TX
?

Physical

Dimensions (w×h×d)
300 × 178 × 102 mm (11.81 × 7.01 × 4.02 in)
Weight
?
Form factor
Mobile
Manufactured
Between 1958 and 1959 in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
5060
MPN
MORROW-MB-000565

Manuals, diagrams and brochures

Morrow MB565 Instruction Manual PDF - 2.12 MB, submitted by RigReference
