The GRC-3030 was used by the Dutch armed forces between 1958 and 1970 as a vehicle mounted radio. It was replacing the aged Wireless Set 19. The GRC-3030 covers 2-12 MHz in 3 bands: 2-3.7, 3.6-6.7 and 6.6-12 MHz and supports AM and CW. The DY-3030 / GRC-3030 power supply unit converts 24V DC to the required internal voltages.
General characteristics
- HAM bands
- ?
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 2-12 MHz
- Modulations
- AM CW
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- Single conversion
- IF-frequencies
- 465 kHz
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 2-12 MHz
- Modulations
- AM CW
- RF-output
- 10/12.5 W
Connections
- Antenna
- BNC + Proprietary (military)
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 24V DC
- Current drain RX
- ?
- TX
- ?
Physical
- Dimensions (w×h×d)
- 245 × 475 × 295 mm (9.65 × 18.70 × 11.61 in)
- Weight
- 21.50 kg (47.4 lbs)
- Form factor
- Mobile
- Manufactured
- Between 1958 and 1970 in Netherlands
Other features
- Usage
- Military communication
- Features + options
- -
- Accessories
- -
- RigReference ID
- 5179
- MPN
- VAN-DER-HEEM-GRC-003030
Manuals, diagrams and brochures
- GRC-3030 Circuit Diagram PDF - Unknown size, submitted by RigReference
- GRC-3030 Alignment procedure (Dutch) PDF - Unknown size, submitted by RigReference
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Van der Heem GRC-3030. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the Van der Heem GRC-3030 in Good condition is around:
- EUR 352 ~ EUR 600
These estimates are based on the following prices:
