The ICOM IC-2700H is introduced by the newly established Noble Radio in 2013. The VHF transceiver covers both 6 meter and the somewhat unusual 4 meter band (70 MHz) in CW and SSB. The rig does not support FM, which is popular among _green radio_ enthusiasts on these bands.
General characteristics
- HAM bands
- 6m 2m
- Frequency stability
- ?
- Tuning steps
- 10 Hz, variable speed
- Memories
- 20 channels in 2 bank(s)
Receiver
- RX-range
- 69.9-70.5 (4m) / 50-52 (6m) MHz
- Modulations
- CW USB LSB
- Sensitivity
- MDS = -130 dbm
- Selectivity
- 500 Hz to 4 kHz adjustable with the SCAF filters
- Filters
- 15 kHz
- Receiver system
- Double conversion, down-converting design. Side-band elimination using phasing techniques with digitally generated Quadrature carriers and Image Reject Mixers preceded by 15 kHz crystal roofing filters.
- IF-frequencies
- 1st: 10.7 MHz
2nd: 25 kHz - Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 69.9-70.5 (4m) / 50-52 (6m) MHz
- Modulations
- CW USB LSB
- RF-output
- 20 Watts CW or PEP SSB
Connections
- Antenna
- -
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 11.5-14 V DC
- Current drain RX
- ?
- TX
- 3.6 A max
Physical
- Dimensions (w×h×d)
- 203 × 95 × 305 mm (7.99 × 3.74 × 12.01 in)
- Weight
- 1.80 kg (4.0 lbs)
- Form factor
- Mobile
- Manufactured
- Between 2013 and 20xx in USA
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Fully PC-controllable
10.7 MHz IF-signal output - Accessories
- -
- RigReference ID
- 6025
- MPN
- NOBLE-RADIO-NR-000006N4
Manuals, diagrams and brochures
- Noble Radio NR-6N4 Preliminary technical specs PDF - Unknown size, submitted by RigReference
