The Vero Global Communication VR-6900 is a dual band FM transceiver. Frequency range RX: 78-174 / 350-520 MHz, TX: 136-174 / 400-480 MHz. Frequency stability: ± 2.5 p.p.m. Tuning steps (kHz): 5 / 6.25 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 / 200 kHz. Receiver system: FM/AM: double conversion. RF output (W): VHF/UHF: 45/40, 25/25, 8/8 W. Memory banks: 4. Memory channels: 512. Power requirements: 13.8 V DC. Features: Detachable front panel, upgradable firmware, optional APRS, optional Bluetooth speaker/mic, color display, band-scope. Current drain RX: 0.5 A. Current drain TX: 10 A max.
General characteristics
- HAM bands
- 2m 70cm
- Frequency stability
- ± 2.5 p.p.m.
- Tuning steps
- 5 / 6.25 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 / 200 kHz
- Memories
- 512 channels in 4 bank(s)
Receiver
- RX-range
- 78-174 / 350-520 MHz
- Modulations
- AM FM N-FM W-FM
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- FM/AM: double conversion
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 136-174 / 400-480 MHz
- Modulations
- FM N-FM
- RF-output
- VHF/UHF: 45/40, 25/25, 8/8 W
Connections
- Antenna
- -
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 13.8 V DC
- Current drain RX
- 0.5 A
- TX
- 10 A max
Physical
- Dimensions (w×h×d)
- ?
- Weight
- ?
- Form factor
- Mobile
- Manufactured
- Between 2018 and 20xx in China
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Detachable front panel
Upgradable firmware
Optional APRS
Optional Bluetooth speaker/mic
Color display
Band-scope - Accessories
- -
- RigReference ID
- 6406
- MPN
- VERO-GLOBAL-COMMUNICATION-VR-006900
Manuals, diagrams and brochures
- VGC VR-6900 PDF - 856.2 kB, submitted by Paul Pate
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Vero Global Communication VR-6900. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
These estimates are based on the following prices:
