General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  6m
Frequency stability
±0.5 p.p.m. (after 1 minute @+14 °F to +122 °F [–10 °C to +50 °C])
Tuning steps
AM/CW/SSB: 1/10 Hz, FM: 0.1 kHz
Memories
?

Receiver

RX-range
0.03-56 MHz
Modulations
AM   FM   CW   USB   LSB   RTTY
Sensitivity
SSB (BW: 2.4 kHz, 10 dB S+N/N)
4 µV (0.5 - 1.8 MHz) (IPO “ON”)
0.16 µV (1.8 - 30 MHz) (RF AMP 2 “ON”)
0.125 µV (50 - 54 MHz) (RF AMP 2 “ON”)
AM (BW: 6 kHz, 10 dB S+N/N, 30 % modulation @400 Hz)
28 µV (0.5 - 1.8 MHz) (IPO “ON”)
2 µV (1.8 - 30 MHz) (RF AMP 2 “ON”)
1 µV (50 - 54 MHz) (RF AMP 2 “ON”)
FM (BW: 15 kHz, 12 dB SINAD)
0.5 µV (28 - 30 MHz) (RF AMP 2 “ON”)
0.35 µV (50 - 54 MHz) (RF AMP 2 “ON”)
Selectivity
CW/RTTY/PKT 0.5 kHz or better 750 Hz or less
SSB 2.4 kHz or better 3.6 kHz or less
AM 6 kHz or better 15 kHz or less
FM 15 kHz or better 25 kHz or less
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: Main: 9 MHz
2nd: Main: 30 kHz (SSB/CW), 24 kHz (FM/AM)
Image rejection
HF: ≥ 70 dB 6m: ≥ 60 dB
Audio output
2.5 W into 4 Ohms with 10% THD

Transmitter

TX-range
1.8-54 MHz (amateur bands only)
Modulations
AM   FM   CW   USB   LSB   RTTY
RF-output
5-100 W (AM: 2-25 W)

Connections

Antenna
SO-239
Impedance
50 (16.7-150 depending on band)Ω
Other
-

Electrical

Power requirements
13.8 V DC ± 10% (Negative Ground)
Current drain RX
1.8-2.1 A
TX
23 A

Physical

Dimensions (w×h×d)
365 × 115 × 312 mm (14.37 × 4.53 × 12.28 in)
Weight
10.00 kg (22.1 lbs)
Form factor
Base Station
Manufactured
Between 2012 and 20xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Hi-perf crystal roofing filters
4.3 inch TFT screen
High speed spectrum scope
32-bit IF-DSP
9 MHz IF output
Built-in auto-ATU
USB, CAT and µ-tune ports
3 × SO-239 connectors
Accessories
-
RigReference ID
5552
MPN
YAESU-FTDX003000

Manuals, diagrams and brochures

Yaesu FTDx-3000 Leaflet PDF - 8.36 MB, submitted by RigReference
Yaesu FTDx-3000 Operation Manual PDF - 32.53 MB, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
Look no further 6 years ago by G0CMF

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FTdx3000. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FTdx3000 is around:

  • EUR 1478.00
  • USD 2159.00 ~ USD 1468.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 1469.95 New / Mint GigaParts
2017 USD 3000.00 New / Mint nd3q
2017 USD 2195.00 New / Mint Marc
2014 EUR 1800.00 Used / Mint iz2uqe
2014 EUR 1800.00 Used / Mint iz2uqe
