Alinco DR-M50H

Mobile VHF/UHF Transceiver

Specs Manuals (0) Reviews (0) Prices (0) Compare

Find Alinco DR-M50H rigs and spare parts on eBay

The Alinco DR-M50H is a mobile VHF/UHF transceiver. It covers 144-146 / 430-440 MHz for both transmit and receive. Image rejection is 60 dB. RF output is selectable between High: 50/35 W and Low: 5/5 W. It features Twin RX and has 1 memory bank with 100 channels. The DR-M50H requires 13.8V DC power, draws 1.2 A in receive mode and a maximum of 11.5 A in transmit mode. Dimensions are 40 × 140 × 176 mm.

General characteristics

HAM bands: 2m 70cm
Frequency stability: ?
Tuning steps: ?
Memories: 100 channels in 1 bank(s)

Receiver

RX-range: 144-146 / 430-440 MHz
Modulations: FM
Sensitivity: ?
Selectivity: 6 kHz (-6 dB), 14 kHz (-60 dB)
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: 60 dB
Audio output: ?

Transmitter

TX-range: 144-146 / 430-440 MHz
Modulations: FM
RF-output: High: 50/35 W, Low: 5/5 W

Connections

Antenna: -
Impedance: 50 Ω
Other: -

Electrical

Power requirements: 13.8V DC
Current drain RX: 1.2 A
TX: Max 11.5 A

Physical

Dimensions (w×h×d): 140 × 40 × 176 mm (5.51 × 1.57 × 6.93 in)
Weight: 1.10 kg (2.4 lbs)
Form factor: Mobile
Manufactured: Between 200x and 200x in Japan

Other features

Usage: Amateur / Ham radio operators
Features + options: Twin RX.
Accessories: -
RigReference ID: 2343
MPN: ALINCO-DR-M000050H
