Uniden-Bearcat BC220FB

General characteristics

HAM bands

2m

Frequency stability

?

Tuning steps

5 kHz

Memories

20 channels in 4 bank(s) @ 11 channels/second

Receiver

RX-range

66-88 / 118-136 / 144-174 / 420-512 MHz

Modulations

AM   FM

Sensitivity

VHF AM: 1 µV (10 dB S/N)
VHF FM: 0.4 µV (12 dB SINAD)
UHF: 0.8 µV (12 dB SINAD)

Selectivity

?

Filters

?

Receiver system

Double conversion superheterodyne

IF-frequencies

1st: 10.8 MHz
2nd: 400 KHz

Image rejection

?

Audio output

?

Connections

Antenna

TV-antenne

Impedance

50/75 Ω

Other

-

Electrical

Power requirements

13.8V DC or mains

Current drain RX

550-770 mA @ 13.8 VDC

TX

-

Physical

Dimensions (w×h×d)

265 × 75 × 195 mm (10.43 × 2.95 × 7.68 in)

Weight

2.40 kg (5.3 lbs)

Form factor

Base Station

Manufactured

Between 1979 and 198x in USA

Other features

Usage

Amateur / Ham radio operators

Features + options

-

Accessories

-

RigReference ID

2448

MPN

UNIDEN-BEARCAT-BC000220FB
