Eddystone 909A

Desktop Shortwave receiver

Specs Manuals (0) Reviews (0) Prices (0) Compare

Find Eddystone 909A rigs and spare parts on eBay

The Eddystone 909A is a desktop shortwave receiver. It covers 1.6-2.7 / 2.7-4.7 MHz with continuous tuning steps. Image rejection is better than 90 dB. The receiver requires 24V DC or mains power and draws 70 mA @ 100-150 VAC in receive mode. Dimensions are 220 × 430 × 250 mm.

General characteristics

HAM bands: 160m 80m
Frequency stability: ?
Tuning steps: Continuous
Memories: None

Receiver

RX-range: 1.6-2.7 / 2.7-4.7 MHz
Modulations: AM CW
Sensitivity: Better than 10 µV
Selectivity: ?
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: Better than 90 dB
Audio output: ?

Connections

Antenna: -
Impedance: 50Ω
Other: -

Electrical

Power requirements: 24V DC or mains
Current drain RX: 70 mA @ 100-150 VAC
TX: -

Physical

Dimensions (w×h×d): 430 × 220 × 250 mm (16.93 × 8.66 × 9.84 in)
Weight: 14.00 kg (30.9 lbs)
Form factor: Base Station
Manufactured: Between 1964 and 196x in Great Britain

Other features

Usage: Amateur / Ham radio operators
Features + options: -
Accessories: -
RigReference ID: 2623
MPN: EDDYSTONE-000909A
