Eddystone EC10

Desktop Shortwave receiver

Specs Manuals (2) Reviews (0) Prices (0) Compare

Find Eddystone EC10 rigs and spare parts on eBay

The Eddystone EC10 is a desktop shortwave receiver covering 0.55-30 MHz in 5 bands. It features filters of 5 kHz (6 dB) and 25 kHz (40 dB). The IF frequency is 465 kHz. Audio output is 1 W. The receiver weighs 5.8 kg less batteries. Current drain in receive mode is 36-180 mA. Dimensions are 162 × 317 × 203 mm.

General characteristics

HAM bands: ?
Frequency stability: ?
Tuning steps: ?
Memories: ?

Receiver

RX-range: 0.55-30 MHz in 5 bands
Modulations: AM CW SSB
Sensitivity: better than 5 µV (15 µV for 550-1500 kHz)
Selectivity: ?
Filters: 5 kHz (6 dB) 25 kHz (40 dB)
Receiver system: ?
IF-frequencies: 465 kHz
Image rejection: ?
Audio output: 1 W

Connections

Antenna: SO-239
Impedance: 75/400Ω
Other: -

Electrical

Power requirements: Mains, 12V DC or 6×U2 cells
Current drain RX: 36-180 mA
TX: -

Physical

Dimensions (w×h×d): 317 × 162 × 203 mm (12.48 × 6.38 × 7.99 in)
Weight: 5.80 kg (12.8 lbs) less batteries
Form factor: Base Station
Manufactured: Between 1967 and 196x in Great Britain

Other features

Usage: Marine / Navy
Features + options: -
Accessories: -
RigReference ID: 2628
MPN: EDDYSTONE-EC000010

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: Eddystone EC-10 Brochure PDF - Unknown size, submitted by RigReference
: Eddystone Ec10 HF Reciever Service Manual PDF - 835.8 kB, submitted by Berend
