The Geloso G4/223 is a transmitter operating on 80-10 meters with frequencies of 3.5-4 / 7-7.5 / 14-14.5 / 21-21.5 / 28-29 / 29-30 MHz. Frequency stability is less than 500 Hz variation. RF output is 50 W. The transmitter operates on mains power (110 / 125 / 140 / 160 / 220 / 280 V AC, 50-60 Hz) and has a maximum current drain of 195 VA during transmit. Dimensions are 260 × 520 × 250 mm.
General characteristics
- HAM bands
- 80m 40m 20m 15m 10m
- Frequency stability
- less than 500 Hz variation
- Tuning steps
- Continuous
- Memories
- None
Transmitter
- TX-range
- 80-10 m
3.5-4 / 7-7.5 / 14-14.5 / 21-21.5 / 28-29 / 29-30 MHz - Modulations
- AM CW
- RF-output
- 50 W
Connections
- Antenna
- SO-239
- Impedance
- 40-1000Ω
- Other
- -
Electrical
- Power requirements
- Mains (110 / 125 / 140 / 160 / 220 / 280 V AC, 50-60 Hz)
- Current drain RX
- -
- TX
- 195 VA max
Physical
- Dimensions (w×h×d)
- 520 × 260 × 250 mm (20.47 × 10.24 × 9.84 in)
- Weight
- ?
- Form factor
- Base Station
- Manufactured
- Between 1964 and 1966 in Italy
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 2678
- MPN
- GELOSO-G000004/223
Manuals, diagrams and brochures
- Geloso G4/223 Instruction Manual (En/It) PDF - 2.44 MB, submitted by RigReference
