Crystal controlled CW transmitter covering 80 to 10 meters. RF-output 25 watts max., on the higher bands the output drops off somewhat and makes 12 watts on 10 meters. Unit comes with a pilot-lamp type tuning indicator and a set of 40 meter coils. The tuning indicator light could be replaced by the optional tuning meter model SM-17. Additional coil-sets were priced at USD 7,50
New price 1947 in the US: $69.50
General characteristics
- HAM bands
- 80m 40m 20m 15m 10m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- None
Transmitter
- TX-range
- 10, 15, 20, 40 & 80 m
- Modulations
- CW
- RF-output
- 10-20 m: 10 W, 40-80 m: 15 W
Connections
- Antenna
- Clamps / screws
- Impedance
- ?
- Other
- -
Electrical
- Power requirements
- Mains (105-125 V AC)
- Current drain RX
- -
- TX
- ?
Physical
- Dimensions (w×h×d)
- 328 × 188 × 218 mm (12.91 × 7.40 × 8.58 in)
- Weight
- 9.50 kg (21.0 lbs)
- Form factor
- Unknown
- Manufactured
- Between 1947 and 194x in USA
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 2742
- MPN
- HALLICRAFTERS-HT-000017
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Hallicrafters HT-17. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the Hallicrafters HT-17 in Good condition is around:
- USD 85
These estimates are based on the following prices:
