Handic 006 (Newer)

General characteristics

HAM bands

2m

Frequency stability

?

Tuning steps

?

Memories

8 channels in 1 bank(s) @ 20 channels/second

Receiver

RX-range

68-88 / 144-174 MHz

Modulations

FM

Sensitivity

1.0 µV

Selectivity

13.5 kHz (-6 dB)
20 kHz (-60 dB)

Filters

?

Receiver system

Crystal controlled double conversion

IF-frequencies

1st: 10.7 MHz
2nd: 455 kHz

Image rejection

35 dB

Audio output

2 W into 8 ohms

Connections

Antenna

KOK1 (Motorola/DIN41585)

Impedance

50/75 Ω

Other

-

Electrical

Power requirements

12-15 V DC

Current drain RX

10 W

TX

-

Physical

Dimensions (w×h×d)

115 × 45 × 165 mm (4.53 × 1.77 × 6.50 in)

Weight

?

Form factor

Mobile

Manufactured

Between 1974 and 1986

Other features

Usage

Amateur / Ham radio operators

Features + options

-

Accessories

-

RigReference ID

2883

MPN

HANDIC-000006-(NEWER)

Manuals, diagrams and brochures

Handic 006 Owner's Manual PDF - Unknown size, submitted by RigReference
