The ICOM IC-1200 is a handheld UHF transceiver. It covers 1240-1300 MHz for both receive and transmit. The IC-1200 has selectable tuning steps of 12.5 or 25 kHz. RF output power is selectable between High: 10 W and Lo 1 W. It features 1 memory bank with 21 channels. Power requirements are 13.8V DC. The current drain in receive mode is 600-900 mA, and the maximum current drain in transmit mode is 5.5 A. The IC-1200 weighs 1.5 kg.
General characteristics
- HAM bands
- ?
- Frequency stability
- ?
- Tuning steps
- 12.5 / 25 kHz
- Memories
- 21 channels in 1 bank(s)
Receiver
- RX-range
- 1240-1300 MHz
- Modulations
- FM
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 1240-1300 MHz
- Modulations
- FM
- RF-output
- High: 10 W, Lo 1 W
Connections
- Antenna
- N-type
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC
- Current drain RX
- 600-900 mA
- TX
- Max 5.5 A
Physical
- Dimensions (w×h×d)
- ?
- Weight
- 1.50 kg (3.3 lbs)
- Form factor
- Handheld
- Manufactured
- Between 1987 and 19xx in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 2965
- MPN
- ICOM-IC-001200
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-1200. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the ICOM IC-1200 is around:
- AUD 48.00
These estimates are based on the following prices:
