The ICOM IC-21A is a VHF transceiver. It covers 144-146 MHz for both receive and transmit. RF output is 0.5-10 W. The radio operates on 13.8V DC or mains power and weighs 7.2 kg. Dimensions are 111 × 230 × 260 mm. Features include diode matrix programmability.
General characteristics
- HAM bands
- 2m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 144-146 MHz
- Modulations
- FM
- Sensitivity
- 0.4 µV (20 dB S/N)
- Selectivity
- 10 kHz (-6 dB)
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 144-146 MHz
- Modulations
- FM
- RF-output
- 0.5-10 W
Connections
- Antenna
- SO-239
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC or mains
- Current drain RX
- ?
- TX
- ?
Physical
- Dimensions (w×h×d)
- 230 × 111 × 260 mm (9.06 × 4.37 × 10.24 in)
- Weight
- 7.20 kg (15.9 lbs)
- Form factor
- Unknown
- Manufactured
- Between 19xx and 19xx in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Diode matrix programmable
- Accessories
- -
- RigReference ID
- 2987
- MPN
- ICOM-IC-000021A
