ICOM IC-3700

Mobile UHF Transceiver

Specs Manuals (0) Reviews (0) Prices (0) Compare

The ICOM IC-3700 is a Mobile UHF Transceiver. It covers 430-440 / 1240-1300 MHz for both receive and transmit. The RF output is selectable between High: 35/10 W, Medium: 10/10 W, Low: 5/1 W. It requires 13.8V DC power and has a maximum current drain of 1.8 A while receiving and 11.5 A while transmitting. The radio weighs 1.5 kg and measures 40 × 140 × 177 mm.

General characteristics

HAM bands: 70cm
Frequency stability: ?
Tuning steps: ?
Memories: ?

Receiver

RX-range: 430-440 / 1240-1300 MHz
Modulations: FM
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: ?
Audio output: ?

Transmitter

TX-range: 430-440 / 1240-1300 MHz
Modulations: FM
RF-output: High: 35/10 W, Medium: 10/10 W, Low: 5/1 W

Connections

Antenna: N-type
Impedance: 50 Ω
Other: -

Electrical

Power requirements: 13.8V DC
Current drain RX: Max 1.8 A
TX: Max 11.5 A

Physical

Dimensions (w×h×d): 140 × 40 × 177 mm (5.51 × 1.57 × 6.97 in)
Weight: 1.50 kg (3.3 lbs)
Form factor: Mobile
Manufactured: Between 199x and 19xx

Other features

Usage: Amateur / Ham radio operators
Features + options: -
Accessories: -
RigReference ID: 3078
MPN: ICOM-IC-003700

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: No documents available for this particular model.

: Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-3700. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on similar Transceiver equipment, the estimated value of the ICOM IC-3700 is around:

USD 210 ~ USD 390

This estimate is based on similar equipment and may not reflect the exact value of this model.
