ICOM IC-475H

Desktop UHF Transceiver

Specs Manuals (0) Reviews (0) Prices (0) Compare

Find ICOM IC-475H rigs and spare parts on eBay

The ICOM IC-475H is a desktop UHF transceiver. It covers 430-440 MHz (Europe) or 430-450 MHz (USA) for both transmit and receive. The RF output power is selectable from 10 to 75 watts. It has 1 memory bank with 99 channels. Power requirements are 13.8V DC. The current drain is 1.1-1.3A in receive mode and a maximum of 20A in transmit mode. Dimensions are 95 × 241 × 239 mm. The IC-475H was manufactured from 1987 to 19xx.

General characteristics

HAM bands: 70cm
Frequency stability: ?
Tuning steps: ?
Memories: 99 channels in 1 bank(s)

Receiver

RX-range: 430-440 MHz (Europe)
430-450 MHz (USA)
Modulations: FM CW SSB
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: ?
Audio output: ?

Transmitter

TX-range: 430-440 MHz (Europe)
430-450 MHz (USA)
Modulations: FM CW SSB
RF-output: 10-75 W

Connections

Antenna: N-type
Impedance: 50 Ω
Other: -

Electrical

Power requirements: 13.8V DC
Current drain RX: 1.1-1.3 A
TX: Max 20 A

Physical

Dimensions (w×h×d): 241 × 95 × 239 mm (9.49 × 3.74 × 9.41 in)
Weight: 6.00 kg (13.2 lbs)
Form factor: Base Station
Manufactured: Between 1987 and 19xx

Other features

Usage: Amateur / Ham radio operators
Features + options: -
Accessories: -
RigReference ID: 3099
MPN: ICOM-IC-000475H
