ICOM IC-481H

Mobile UHF Transceiver

Specs Manuals (0) Reviews (0) Prices (0) Compare

The ICOM IC-481H is a mobile UHF transceiver. It covers 136-174 / 400-479 MHz for reception and transmits on 430-440 MHz (Europe) or 440-450 MHz (USA). The RF output power is switchable between High: 35 W, Medium: 10 W, Low: 5 W. It requires 13.8V DC power and draws a maximum of 10.5A during transmit. Dimensions are 40 × 140 × 171 mm. The radio weighs 960 gr.

General characteristics

HAM bands: 70cm
Frequency stability: ?
Tuning steps: ?
Memories: ?

Receiver

RX-range: 136-174 / 400-479 MHz
Modulations: FM
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: ?
Audio output: ?

Transmitter

TX-range: 430-440 MHz (Europe)
440-450 MHz (USA)
Modulations: FM
RF-output: High: 35 W, Medium: 10 W, Low: 5 W

Connections

Antenna: N-type
Impedance: 50 Ω
Other: -

Electrical

Power requirements: 13.8V DC
Current drain RX: 1 A
TX: Max 10.5 A

Physical

Dimensions (w×h×d): 140 × 40 × 171 mm (5.51 × 1.57 × 6.73 in)
Weight: 960 gr (2.1 lbs)
Form factor: Mobile
Manufactured: Between 199x and 199x

Other features

Usage: Amateur / Ham radio operators
Features + options: -
Accessories: -
RigReference ID: 3101
MPN: ICOM-IC-000481H

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: No documents available for this particular model.

: Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-481H. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on similar Transceiver equipment, the estimated value of the ICOM IC-481H is around:

USD 210 ~ USD 390

This estimate is based on similar equipment and may not reflect the exact value of this model.

These estimates are based on the following prices:

Year	Historic price	Condition	Submitted by

Login or Register to submit prices
