10m/6m/23cm FM & 2m SSB/CW option.

General characteristics

HAM bands
70cm
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
140-150 / 440-450 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
140-150 / 440-450 MHz
Modulations
FM
RF-output
High: 50/35 W, Low: 5/5 W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
11-16V DC
Current drain RX
0.85-1.4 A
TX
Max 12 A

Physical

Dimensions (w×h×d)
150 × 50 × 191 mm (5.91 × 1.97 × 7.52 in)
Weight
1.60 kg (3.5 lbs)
Form factor
Unknown
Manufactured
Between 1989 and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
Twin RX
Accessories
-
RigReference ID
3178
MPN
ICOM-IC-000901A
