General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
280 channels in 1 bank(s)

Receiver

RX-range
144-146 / 430-440 MHz
Modulations
FM
Sensitivity
<0.16 µV (12 dB SINAD)
Selectivity
12 kHz (-6 dB), 28 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz
Modulations
FM
RF-output
High: 50/35 W, Medium: 10/10 W, Low: 5/5 W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
Max 1 A
TX
Max 11 A

Physical

Dimensions (w×h×d)
140 × 40 × 189 mm (5.51 × 1.57 × 7.44 in)
Weight
1.20 kg (2.6 lbs)
Form factor
Mobile
Manufactured
Between 199x and xxxx

Other features

Usage
Amateur / Ham radio operators
Features + options
9k6 packet ready. Alpha tags. Twin RX
Accessories
-
RigReference ID
3437
MPN
KENWOOD-TM-V000007E

Manuals, diagrams and brochures

Kenwood TM V7 User Manual PDF - 2.38 MB, submitted by p H
Tmv7AE Service PDF - 6.86 MB, submitted by p H

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood TM-V7E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Kenwood TM-V7E is around:

  • EUR 99.00
  • USD 27.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2023 EUR 100.00 Used / Okay Tom Nilssen
2023 EUR 100.00 Used / Good Tom Nilssen
2010 USD 169.95 New / Good universal-radio
