The Kenwood TR-851E is a Mobile UHF Transceiver. It covers 430-440 MHz for both receive and transmit frequencies. The radio has an image rejection better than 60 dB and offers RF output of 25 W (High) or 5 W (Low). It features 1 memory bank with 10 channels. The TR-851E requires 11-16V DC power, drawing a maximum of 1 A in receive mode and 7.5 A in transmit mode. Dimensions are 60 × 180 × 215 mm and it weighs 2.5 kg.
General characteristics
- HAM bands
- 70cm
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- 10 channels in 1 bank(s)
Receiver
- RX-range
- 430-440 MHz
- Modulations
- All mode
- Sensitivity
- SSB/CW: Better than 0.11 µV (10 dB S+N/N)
FM: Better than 0.18 µV (12 dB SINAD) - Selectivity
- SSB/CW: 2.2 kHz (-6 dB), 4.8 kHz (-60 dB)
FM: 12 kHz (-6 dB), 24 kHz (-60 dB) - Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- Better than 60 dB
- Audio output
- ?
Transmitter
- TX-range
- 430-440 MHz
- Modulations
- All mode
- RF-output
- High: 25 W, Low: 5 W
Connections
- Antenna
- N-type
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 11-16V DC
- Current drain RX
- Max 1 A
- TX
- Max 7.5 A
Physical
- Dimensions (w×h×d)
- 180 × 60 × 215 mm (7.09 × 2.36 × 8.46 in)
- Weight
- 2.50 kg (5.5 lbs)
- Form factor
- Mobile
- Manufactured
- Between 1987 and 19xx
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 3469
- MPN
- KENWOOD-TR-000851E
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood TR-851E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on similar Transceiver equipment, the estimated value of the Kenwood TR-851E is around:
- USD 224 ~ USD 415
This estimate is based on similar equipment and may not reflect the exact value of this model.
