The Communications Receiver Type RA.117 has been designed for use as a general purpose receiver which will provide a high order of selectivity and stability. The receiver covers a frequency range from 1.0 to 30.0 Mc/s.
The receiver is designed for both bench (table) and rack mounting. The front panel is painted Light Battleship Grey (British Standard Specifcation 381C, colour 697) and has been carefully designed to minimize operator fatigue.
The chassis and major modules are of cast construction thus ensuring maximum rigidity and effective electrical screening. Each receiver is supplied with three keys to facilitate removal of the control knobs, insulated trimming tool and coaxial terminations for aerial and I.F. connections. Extra sleeves can be provided with the terminations for alternative coaxial cable sizes.
The RA.117 is basically an upgraded RA-17L.
General characteristics
- HAM bands
- ?
- Frequency stability
- Afterwarm-up, overall drift is less than 50 c/s per hour under conditions of constant supply voltage and ambient temperature.
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 1-30 MHz
- Modulations
- -
- Sensitivity
- A1 reception, bandwidth 3 Kc/s; 1µV for 18dB signal-to-noise ratio.
A2 reception, 30% modulated, bandwidth 3 Kc/s; 3µV for 18dB signal-to-noise ratio. - Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- 1 W @ 5% THD
Connections
- Antenna
- -
- Impedance
- 75 / 2000Ω
- Other
- -
Electrical
- Power requirements
- 100-125V and 200-250V, 45-65 c/s.
- Current drain RX
- 100W approx.
- TX
- -
Physical
- Dimensions (w×h×d)
- 482 × 267 × 510 mm (18.98 × 10.51 × 20.08 in) rack mounted
- Weight
- 28.00 kg (61.8 lbs) rack mounted
- Form factor
- Base Station
- Manufactured
- Between 19xx and 19xx in Great Britain
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Automatic Volume Control
- Accessories
- -
- RigReference ID
- 3693
- MPN
- RACAL-RA-000117
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Racal RA-117. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the Racal RA-117 is around:
- EUR 9.00
These estimates are based on the following prices:
