Regency HX-2000

General characteristics

HAM bands

2m  70cm

Frequency stability

?

Tuning steps

5 / 10 / 12.5 / 25 kHz

Memories

100 channels in 1 bank(s)

Receiver

RX-range

118-136 / 138-174 / 406-512 / 800-950 MHz (USA)

Modulations

AM   FM

Sensitivity

AM (12 dB SINAD)
118-136 MHz: 0.5 µV
FM (12 dB SINAD)
138-174 MHz: 0.5 µV
406-512 MHz: 0.7 µV
800-950 MHz: 0.7 µV

Selectivity

15 kHz (-6 dB)

Filters

?

Receiver system

Double conversion superheterodyne

IF-frequencies

1st: 21.4 MHz
2nd: 455 kHz

Image rejection

?

Audio output

120 mW at 10% distortion

Connections

Antenna

Proprietary

Impedance

50Ω

Other

-

Electrical

Power requirements

4.8-6 V DC (4 R6/AA cells) or 6 V DC external

Current drain RX

?

TX

-

Physical

Dimensions (w×h×d)

77 × 174 × 39 mm (3.03 × 6.85 × 1.54 in)

Weight

425 gr (15.0 oz) with batteries

Form factor

Handheld

Manufactured

Between 198x and 198x in Japan

Other features

Usage

Amateur / Ham radio operators

Features + options

-

Accessories

-

RigReference ID

3729

MPN

REGENCY-HX-002000

Manuals, diagrams and brochures

No manuals yet for the Regency HX-2000. Have a PDF of the user manual, service manual, or schematic? Upload it and help the next operator.



Upload relevant documents

Reviews

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Regency HX-2000. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Regency HX-2000 in Good condition is around:

• USD 39
