Rohde & Schwarz ESM-180

General characteristics

HAM bands

6m  2m  4m

Frequency stability

± 0.01 %, crystal controlled

Tuning steps

40 / 200 kHz

Memories

None

Receiver

RX-range

30-180 MHz in 5 bands

Modulations

AM   FM   CW

Sensitivity

N-AM, band 1-4: 2.5 µV
N-AM, band 5: 5 µV
FM, band 1-4: 2 µV
FM, band 5: 4 µV

Selectivity

Narrow-band: 0.3-3 kHz
Wide-band: 0.03-15 kHz

Filters

?

Receiver system

Single / Double conversion superheterodyne

IF-frequencies

21.4 / 3.4 MHz

Image rejection

Band 1-4: 80 dB, band 5: 60 dB

Audio output

500 mW or AF output socket

Connections

Antenna

Proprietary

Impedance

60Ω

Other

Dezifix B (R&S)

Electrical

Power requirements

Mains

Current drain RX

110 VA

TX

-

Physical

Dimensions (w×h×d)

540 × 234 × 378 mm (21.26 × 9.21 × 14.88 in)

Weight

28.00 kg (61.8 lbs)

Form factor

Base Station

Manufactured

Between 196x and 196x in West Germany

Other features

Usage

Amateur / Ham radio operators

Features + options

-

Accessories

-

RigReference ID

3763

MPN

ROHDE-SCHWARZ-ESM-000180

Manuals, diagrams and brochures

Rohde-Schwarz ESM-180 Instruction Book PDF - 1.10 MB, submitted by Eric R



Upload relevant documents

Reviews & stories

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Rohde & Schwarz ESM-180. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Rohde & Schwarz ESM-180 is around:

• EUR 805.00 ~ EUR 428.00

Price History Chart

These estimates are based on the following prices:
