The RadioShack / Realistic HTX-212 is a Mobile VHF Transceiver. It covers 136-174 MHz in receive and 144.6-148 MHz in transmit. Frequency stability is ± 10 p.p.m. with tuning steps of 5, 10, 12.5, 20, 25, 50, and 100 kHz. It uses a Double conversion superheterodyne receiver system with IF frequencies of 21.4 MHz and 455 kHz. RF output is 10/45 W and audio output is 2 W, 10% THD, 8 Ohms. The HTX-212 features CTCSS and DTMF. It requires 13.8 V DC +/- 15 % power. Current drain is 200 mA in receive and 3.7-9 A in transmit. Dimensions are 42 × 142 × 160 mm.
General characteristics
- HAM bands
- 2m
- Frequency stability
- ± 10 p.p.m.
- Tuning steps
- 5 / 10 / 12.5 / 20 / 25 / 50 / 100 kHz
- Memories
- None
Receiver
- RX-range
- 136-174 MHz
- Modulations
- FM
- Sensitivity
- 0.25 µV (12 dB SINAD)
- Selectivity
- 7.5 kHz
- Filters
- ?
- Receiver system
- Double conversion superheterodyne
- IF-frequencies
- 21.4 MHz / 455 kHz
- Image rejection
- ?
- Audio output
- 2 W, 10% THD, 8 Ohms
Transmitter
- TX-range
- 144.6-148 MHz
- Modulations
- FM
- RF-output
- 10 / 45 W
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 13.8 V DC +/- 15 %
- Current drain RX
- 200 mA
- TX
- 3.7-9 A
Physical
- Dimensions (w×h×d)
- 142 × 42 × 160 mm (5.59 × 1.65 × 6.30 in)
- Weight
- ?
- Form factor
- Mobile
- Manufactured
- Between 1995 and 199x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- CTCSS and DTMF
- Accessories
- -
- RigReference ID
- 3769
- MPN
- RADIOSHACK-REALISTIC-HTX-000212
Manuals, diagrams and brochures
- RadioShack HTX-212 Owner's Manual PDF - 334.0 kB, submitted by Gerd
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used RadioShack / Realistic HTX-212. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the RadioShack / Realistic HTX-212 is around:
- USD 2.00 ~ USD 47.00
These estimates are based on the following prices:
