The Yaesu FT-100D is a mobile HF/VHF/UHF transceiver. It covers 10-160 m + WARC / 50-54 / 144-146 / 430-440 MHz for both transmit and receive. The RF output is 100/100/50/20 W (25/25/12.5/5 W AM). It features DSP and CTCSS. The rig requires 13.8V DC power, with a maximum current drain of 1.6 A in receive and 22 A in transmit. Dimensions are 54 × 160 × 205 mm. It weighs 3 kg.
General characteristics
- HAM bands
- 160m 80m 40m 30m (WARC) 20m 17m (WARC) 15m 12m (WARC) 6m 2m 70cm 10m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 10-160 m + WARC / 50-54 / 144-146 / 430-440 MHz
- Modulations
- AM FM CW SSB
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 10-160 m + WARC / 50-54 / 144-146 / 430-440 MHz
- Modulations
- AM FM CW SSB
- RF-output
- 100/100/50/20 W (25/25/12.5/5 W AM)
Connections
- Antenna
- -
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC
- Current drain RX
- Max 1.6 A
- TX
- Max 22 A
Physical
- Dimensions (w×h×d)
- 160 × 54 × 205 mm (6.30 × 2.13 × 8.07 in)
- Weight
- 3.00 kg (6.6 lbs)
- Form factor
- Mobile
- Manufactured
- Between 2000 and 200x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- DSP, CTCSS
- Accessories
- -
- RigReference ID
- 4230
- MPN
- YAESU-FT-000100D
Manuals, diagrams and brochures
- Yaesu FT-100D Operating Manual PDF - Unknown size, submitted by RigReference
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-100D. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the Yaesu FT-100D in Good condition is around:
- CAD 825
- USD 450 ~ USD 500
These estimates are based on the following prices:
