Yaesu FT-212RH

Mobile VHF Transceiver

Specs Manuals (0) Reviews (0) Prices (0) Compare

Find Yaesu FT-212RH rigs and spare parts on eBay

The Yaesu FT-212RH is a mobile VHF transceiver. It covers 144-146 MHz (Europe) or 144-148 MHz (USA) for both receive and transmit. The radio has selectable tuning steps of 5, 10, 12.5, 20, or 25 kHz. RF output power is switchable between high (45 W) and low (5 W). It requires 13.8V DC power and draws 300-500 mA in receive mode and a maximum of 10 A in transmit mode. Dimensions are 40 × 140 × 160 mm and the weight is 1.25 kg.

General characteristics

HAM bands: 2m
Frequency stability: ?
Tuning steps: 5 / 10 / 12.5 / 20 / 25 kHz
Memories: ?

Receiver

RX-range: 144-146 MHz (Europe)
144-148 MHz (USA)
Modulations: FM
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: ?
Audio output: ?

Transmitter

TX-range: 144-146 MHz (Europe)
144-148 MHz (USA)
Modulations: FM
RF-output: High: 45 W, Low: 5 W

Connections

Antenna: -
Impedance: 50 Ω
Other: -

Electrical

Power requirements: 13.8V DC
Current drain RX: 300-500 mA
TX: Max 10 A

Physical

Dimensions (w×h×d): 140 × 40 × 160 mm (5.51 × 1.57 × 6.30 in)
Weight: 1.25 kg (2.8 lbs)
Form factor: Mobile
Manufactured: Between 1988 and 19xx

Other features

Usage: Amateur / Ham radio operators
Features + options: -
Accessories: -
RigReference ID: 4256
MPN: YAESU-FT-000212RH

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!
