The Yaesu FT-2 AUTO is a VHF transceiver. Frequency range for reception and transmission is 144-146 MHz (Europe) or 146-148 MHz (USA). RF output power is selectable between High: 10 W and Low: 1 W. The radio features 1 memory bank with 8 channels. Power requirements are 13.8V DC or mains. Current drain in receive mode is 0.5 A, maximum current drain in transmit mode is 2.1 A. Dimensions are 95 × 210 × 270 mm.
General characteristics
- HAM bands
- 2m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- 8 channels in 1 bank(s)
Receiver
- RX-range
- 144-146 MHz (Europe)
146-148 MHz (USA) - Modulations
- FM
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- XTAL
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 144-146 MHz (Europe)
146-148 MHz (USA) - Modulations
- FM
- RF-output
- High: 10 W, Low: 1 W
Connections
- Antenna
- SO-239
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC or mains
- Current drain RX
- 0.5 A
- TX
- Max 2.1 A
Physical
- Dimensions (w×h×d)
- 210 × 95 × 270 mm (8.27 × 3.74 × 10.63 in)
- Weight
- 4.20 kg (9.3 lbs)
- Form factor
- Unknown
- Manufactured
- Between 197x and 19xx
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 4280
- MPN
- YAESU-FT-000002-AUTO
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-2 AUTO. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the Yaesu FT-2 AUTO in Good condition is around:
- AUD 25
These estimates are based on the following prices:
