FT-7800R: US model
FT-7800E: European model
NOAA Weather ALert (U.S. Version only)
A special memory bank on the FT-7800R allows instant recall of the ten NOAA Weather frequencies. What’s more, you can enable a special “Severe Weather Alert” feature that will sound an alarm when a NOAA station transmits the special alert tone during a severe weather alert broadcast.
Over 1000 Memory Channels
The FT-7800R’s incredible memory channel capacity includes registers for over 1000 channels, each capable of storing a 6-character Alpha-Numeric label. And the memories may be stored in any of the 20 available memory groups; a particular memory channel may also be stored in multiple groups, if desired.
WiRES™ Internet Linking Capability
The FT-7800R’s DTMF signaling capability includes provision for easy access to Yaesu’s WiRES™ (Wide-coverage Internet Repeater Enhancement System) Internet linking nodes, as well as other linking systems that require a DTMF string for access.
YSK-7800 Remote Mounting Kit (option)
Using the optional YSK-7800 Separation Kit, which contains both cabling and a bracket for the remote front panel, you can mount the FT-7800R’s front panel on the vehicle’s dash board, then stow the radio’s body under the seat or in some other convenient, out-of-the-way location. The cables are approximately 20 feet (6 m) in length.
One-Touch "Hyper Memory" Operation
Five front panel keys allow complete transceiver configuration status to be stored for convenient one-touch recall. So you can set up favorite frequencies in each operating band, including the receive-only bands, then recall them with a single touch of a button!
High Power Output
Boasting a big 50 Watts of power output on 144 MHz, and 40 Watts on 430 MHz, the FT-7800R also includes provision for three lower power levels, so you never have to use more power than you really need. The power level is stored in regular and Hyper Memory registers, too
Wide Receiver Frequency Coverage
The FT-7800R provides receiver coverage from 108 to 520 MHz, and 700 to 999.99 MHz (cellular blocked), so you have available a wide range of monitoring excitement, including AM Aircraft, Public Safety, Government, Business, and, of course, Amateur communications. The synthesizer steps appropriate for the operating band are automatically selected, too!
The Yaesu FT-7800 has been replace with the FT-7900 in 2009.
General characteristics
- HAM bands
- 2m 70cm
- Frequency stability
- ± 5 p.p.m. @ 14° F ~ +140° F (–10 °C ~ +60 °C)
- Tuning steps
- 5 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 kHz
- Memories
- 1000 channels in 1 bank(s)
Receiver
- RX-range
- 108-520 / 700-999.99 MHz (cellular blocked in the US)
- Modulations
- FM AFSK
- Sensitivity
- 0.8 µV (TYP) for 10 dB SN (108 - 137 MHz, AM)
0.2 µV for 12 dB SINAD (137 - 150 MHz, FM)
0.25 µV for 12 dB SINAD (150 - 174 MHz, FM)
0.3 µV (TYP) for 12 dB SINAD (174 - 222 MHz, FM)
0.25 µV (TYP) for 12 dB SINAD (222 - 300 MHz, FM)
0.8 µV (TYP) for 10 dB SN (300 - 336 MHz, AM)
0.25 µV for 12 dB SINAD (336 - 420 MHz, FM)
0.2 µV for 12 dB SINAD (420 - 520 MHz, FM)
0.4 µV (TYP) for 12 dB SINAD (800 - 900 MHz, FM)
0.8 µV (TYP) for 12 dB SINAD (900 - 999.99 MHz, FM) - Selectivity
- 12 kHz (-6 dB), 30 kHz (-60 dB)
- Filters
- ?
- Receiver system
- Double conversion superheterodyne
- IF-frequencies
- 45.05 MHz / 450 kHz
- Image rejection
- ?
- Audio output
- 2 W @ 8 Ω for 10 % THD
Transmitter
- TX-range
- 144-148 / 430-450 MHz (USA)
144-146 / 430-440 MHz (Europe) - Modulations
- FM AFSK
- RF-output
- High: 50/40 W, Mid1: 20/20 W, Mid2: 10/10 W, Low: 5/5 W
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 13.8 V DC (±15%), negative ground
- Current drain RX
- 0.5 A max
- TX
- 8.5 A max
Physical
- Dimensions (w×h×d)
- 140 × 42 × 168 mm (5.51 × 1.65 × 6.61 in) w/o knobs & connectors
- Weight
- 1,000 gr (2.2 lbs)
- Form factor
- Mobile
- Manufactured
- Between 2003 and 2009
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Wires and 1200/9600 baud packet ready. Detachable front panel.
Antenna duplexer - Accessories
- -
- RigReference ID
- 4345
- MPN
- YAESU-FT-007800R/E
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-7800R/E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the Yaesu FT-7800R/E is around:
- USD 36.00
- GBP 41.00
These estimates are based on the following prices:
