Also known as Sommerkamp FTdx560. The is also a Yaesu FTdx-401B version which supports AM.
General characteristics
- HAM bands
- 80m 40m 20m 15m 10m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 10-80 m + 30 m
11 m optional - Modulations
- CW SSB
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 10-80 m + 30 m
11 m optional - Modulations
- CW SSB
- RF-output
- SSB: 560 W (PEP input), CW: 430 W (input)
Connections
- Antenna
- -
- Impedance
- 50/100 Ω
- Other
- -
Electrical
- Power requirements
- Mains
- Current drain RX
- ?
- TX
- ?
Physical
- Dimensions (w×h×d)
- 400 × 160 × 350 mm (15.75 × 6.30 × 13.78 in)
- Weight
- 18.14 kg (40.0 lbs)
- Form factor
- Base Station
- Manufactured
- Between 19xx and 19xx in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 4380
- MPN
- YAESU-FTDX-000401
Manuals, diagrams and brochures
- Yaesu FTdx-401 Instruction manual PDF - Unknown size, submitted by RigReference
- Yaesu FT-401 AM addendum PDF - Unknown size, submitted by RigReference
- Schematic-1 of 5 TIFF - 95.4 kB, submitted by Michael Ince
- Schematic-2 of 5 TIFF - 114.5 kB, submitted by Michael Ince
- Schematic-3 of 5 TIFF - 113.8 kB, submitted by Michael Ince
- Schematic-4 of 5 TIFF - 112.6 kB, submitted by Michael Ince
- Schematic-5 of 5 TIFF - 114.9 kB, submitted by Michael Ince
