The FT-7900R provides 50 Watts of power on the 144 MHz band, and 40 Watts on the 430 MHz, and is designed for simplicity of operation along with high performance in the receiver section.

High Power Output
Boasting a big 50 Watts of power output on 144 MHz, and 40 Watts on 430 MHz, the FT-7900R also includes provision for three lower power levels, so you never have to use more power than you really need. The power level is stored in regular and Hyper Memory registers, too
Wide Receiver Frequency Coverage
The FT-7900R provides receiver coverage from 108 to 520 MHz, and 700 to 999.99 MHz (cellular blocked), so you have available a wide range of monitoring excitement, including AM Aircraft, Public Safety, Government, Business, and, of course, Amateur communications. The synthesizer steps appropriate for the operating band are automatically selected, too!
Large LCD Display
The large backlit LCD on the FT-7900R ensure excellent visibility
One-Touch
Five front panel keys allow complete transceiver configuration status to be stored for convenient one-touch recall. So you can set up favorite frequencies in each operating band, including the receive-only bands, and then recall them with a single touch of a button!
Over 1000 Memory Channels
The FT-7900R’s incredible memory channel capacity includes registers for over 1000 channels, each capable of storing a 6-character Alpha-Numeric label. And the memories may be stored in any of the 20 available memory groups; a particular memory channel may also be stored in multiple groups, if desired.
NOAA Weather Alert (U.S. Version only)
A special memory bank on the FT-7900R allows instant recall of the ten NOAA Weather frequencies. What’s more, you can enable a special “Severe Weather Alert” feature that will sound an alarm when a NOAA station transmits the special alert tone during a severe weather alert broadcast.
YSK-7800 Remote Mounting Kit (option)
Using the optional YSK-7800 Separation Kit, which contains both cabling and a bracket for the remote front panel, you can mount the FT-7900R’s front panel on the vehicle’s dash board, then stow the radio’s body under the seat or in some other convenient, out-of-the-way location. The cables are approximately 20 feet (6 m) in length.
WiRES™ Internet Linking Capability
The FT-7900R’s DTMF signaling capability includes provision for easy access to Yaesu’s WiRES™ (Wide-coverage Internet Repeater Enhancement System) Internet linking nodes, as well as other linking systems that require a DTMF string for access.

General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
1000 channels in 1 bank(s)

Receiver

RX-range
108-520 / 700-990 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-148 / 430-450 MHz (USA)
Modulations
FM
RF-output
50W max

Connections

Antenna
-
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Mobile
Manufactured
Between 2009 and 20xx

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS/DCS
Wires II internet
ARTS
1200/9600 baud packet ready
Detachable front panel
Accessories
-
RigReference ID
4515
MPN
YAESU-FT-007900R

Manuals, diagrams and brochures

Yaesu FT-7900R Operation manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
Very dissapointing 13 years ago by hrensin

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-7900R. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-7900R is around:

  • EUR 43.00
  • USD 93.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2015 USD 189.00 New / Mint drguyor
2010 EUR 269.00 New / Good thiecom.de
