The Albrecht AE-4190 comes in three versions:
40 FM 40-channels, FM-only (4 W)
80/12 80-channels FM (4 W), 12-channels AM (1 W)
40/40 40-channels FM (4 W), 40-channels AM (1 W)

General characteristics

HAM bands
11m (CB)
Frequency stability
?
Tuning steps
Channelized
Memories
80 channels in 1 bank(s)

Receiver

RX-range
26-27 MHz (exact range depends on version)
Modulations
AM   FM
Sensitivity
FM better + 2dbmV EMK for 20 dB
AM better + 4dbmV EMK for 12 dB
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
≥ 48 dB
Audio output
2 Watt to 8 Ohm load

Transmitter

TX-range
26-27 MHz (exact range depends on version)
Modulations
AM   FM
RF-output
FM: 4 W, AM: 1 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Mobile
Manufactured
Between 2002 and 20xx in Germany

Other features

Usage
Citizen Band (27Mc)
Features + options
-
Accessories
-
RigReference ID
4706
MPN
ALBRECHT-AE-004190
