The Hy-Gain 9 originally came with 23 channels. A 40 channel unit was available. The PCB was made by Cybernet Enterprise in Japan.

General characteristics

HAM bands
11m (CB)
Frequency stability
?
Tuning steps
Channelized
Memories
23 channels in 1 bank(s)

Receiver

RX-range
26.965-27.255 MHz
Modulations
AM
Sensitivity
0.7 µV for 10 dB (S+N)/N
Selectivity
?
Filters
455 kHz
Receiver system
Dual conversion superheterodyne with RF-amplifier stage and 455 kHz ceramic filter
IF-frequencies
1st: 10.695 MHz
2nd: 455 kHz
Image rejection
?
Audio output
3 W max

Transmitter

TX-range
26.965-27.255 MHz
Modulations
AM
RF-output
4 W max

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
11.5~14.5 V DC, negative or positive ground
Current drain RX
500 mA in standby (no signal)
TX
1.3 A @ 13.8 V DC unmodulated

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Mobile
Manufactured
Between 1976 and 197x in Japan

Other features

Usage
Citizen Band (27Mc)
Features + options
Optional 40 channel unit
Accessories
-
RigReference ID
4795
MPN
HY-GAIN-000009-(2679)
