Midland/Alan 78 Plus

General characteristics

HAM bands

11m (CB)

Frequency stability

?

Tuning steps

Channelized

Memories

400 channels in 1 bank(s)

Receiver

RX-range

26.965-27.405 MHz

Modulations

-

Sensitivity

?

Selectivity

?

Filters

?

Receiver system

?

IF-frequencies

?

Image rejection

?

Audio output

?

Transmitter

TX-range

26.965-27.405 MHz

Modulations

-

RF-output

4 W

Connections

Antenna

-

Impedance

50Ω

Other

-

Electrical

Power requirements

?

Current drain RX

?

TX

?

Physical

Dimensions (w×h×d)

139 × 37 × 182 mm (5.47 × 1.46 × 7.17 in)

Weight

860 gr (1.9 lbs)

Form factor

Handheld

Manufactured

Between 1995 and 2001

Other features

Usage

Citizen Band (27Mc)

Features + options

AM/FM

Accessories

-

RigReference ID

4862

MPN

MIDLAND/ALAN-000078-PLUS

Manuals, diagrams and brochures

Alan 78 Plus Circuit diagram PDF - 258.6 kB, submitted by Gerd

Midland/Alan 78 Plus print board JPEG - 1.95 MB, submitted by Gerd



Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Midland/Alan 78 Plus. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:
