Sommerkamp TS-727GT

Handheld Transceiver

Specs Manuals (1) Reviews (0) Prices (0) Compare

Find Sommerkamp TS-727GT rigs and spare parts on eBay

Find the Sommerkamp TS-727GT on Amazon

The Sommerkamp TS-727GT is a handheld transceiver. The frequency range for both reception and transmission is 26.5-29.7 MHz. Frequency stability is 0.005%. Tuning steps are channelized. RF output is 0.5 W (3 W). Audio output is 0.4 W @ 10% THD. The radio features 1 memory bank with 6 channels. Current drain in receive mode is 100 mA and 180 mA in transmit mode. Dimensions are 35 × 121 × 160 mm without protrusions. Weight is 1.12 kg.

General characteristics

HAM bands: 11m (CB)
Frequency stability: 0.005%
Tuning steps: Channelized
Memories: 6 channels in 1 bank(s)

Receiver

RX-range: 26.5-29.7 MHz
Modulations: AM
Sensitivity: 1 µV for 10 dB S/N
Selectivity: 10 kHz @ -30 dB
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: 11-16 V DC negative ground
Audio output: 0.4 W @ 10% THD

Transmitter

TX-range: 26.5-29.7 MHz
Modulations: AM
RF-output: 0.5 W (3 W)

Connections

Antenna: SO-239
Impedance: 50-52Ω
Other: -

Electrical

Power requirements: ?
Current drain RX: 100 mA
TX: 180 mA

Physical

Dimensions (w×h×d): 121 × 35 × 160 mm (4.76 × 1.38 × 6.30 in) without protrusions
Weight: 1.12 kg (2.5 lbs)
Form factor: Handheld
Manufactured: Between 198x and 198x in Japan

Other features

Usage: Citizen Band (27Mc)
Features + options: -
Accessories: -
RigReference ID: 4937
MPN: SOMMERKAMP-TS-000727GT

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: Sommerkamp TS-727G Instruction Manual PDF - 1.09 MB, submitted by Gerd
