WiNRADiO WR-G31DDC 'Excalibur'

General characteristics

HAM bands

?

Frequency stability

2.5 ppm (0 to 50 °C)

Tuning steps

0.001 kHz

Memories

?

Receiver

RX-range

9 kHz - 50 MHz

Modulations

AM   AM-sync   FM   CW   USB   LSB   DSB   ISB   FSK

Sensitivity

AM: -101 dBm (2.00 µV) @ 10 dB S+N/N, 30% modulation
SSB: -116 dBm (0.35 µV) @ 10 dB S+N/N, 2.1 kHz BW
CW: -123 dBm (0.16 µV) @ 10 dB S+N/N, 500 Hz BW
FM: -112 dBm (0.56 µV) @ 12 dB SINAD, 3 kHz deviation, 12 kHz BW, audio filter 300-3000 Hz, deemphasis -6dB/oct

Selectivity

10 Hz - 2 MHz (selectable in 21 coarse steps, fine adjustment in 1 Hz steps)

Filters

Cut-off frequency 1.8 MHz @ -3 dB Attenuation 60 dB min @ 0.5 MHz

Receiver system

DDirect-sampling, digitally down-converting software-defined receiver

IF-frequencies

?

Image rejection

100 dB

Audio output

?

Connections

Antenna

SMA

Impedance

50Ω

Other

-

Electrical

Power requirements

12V DC

Current drain RX

500 mA

TX

-

Physical

Dimensions (w×h×d)

?

Weight

?

Form factor

Headless

Manufactured

Between 2010 and 20xx

Other features

Usage

Amateur / Ham radio operators

Features + options

DSP
Number of memory channels limited by computer memory
USB 2.0 computer interface

Accessories

-

RigReference ID

5141

MPN

WINRADIO-WR-G000031DDC-'EXCALIBUR'

Manuals, diagrams and brochures

No documents available for this particular model.



Upload relevant documents

Reviews & stories

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used WiNRADiO WR-G31DDC 'Excalibur'. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the WiNRADiO WR-G31DDC 'Excalibur' is around:

• EUR 190.00
• USD 377.00
