WWII. 10 tubes. Mainly used for Army and Air-force purposes.
Surplus price, late forties in the US: $69.95 (less speaker)

General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m
Frequency stability
?
Tuning steps
Continuous
Memories
None

Receiver

RX-range
0.15-1.5 MHz in 4 bands
Modulations
AM   CW
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
Requires high-Z headphones or external speaker LS-3

Connections

Antenna
Proprietary (military)
Impedance
50Ω
Other
-

Electrical

Power requirements
?
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
460 × 254 × 231 mm (18.11 × 10.00 × 9.09 in)
Weight
27.90 kg (61.6 lbs)
Form factor
Base Station
Manufactured
Between 1936 and 1945 in USA

Other features

Usage
Military communication
Features + options
BFO
Accessories
LS-3 external speaker
RigReference ID
5194
MPN
MILITARY-BC-000344

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Military BC-344. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Military BC-344 is around:

  • USD 0.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
1949 USD 69.95 Used / Okay RigReference
