General characteristics

HAM bands
11m (CB)  10m
Frequency stability
?
Tuning steps
Channelized
Memories
40 channels in 1 bank(s)

Receiver

RX-range
26.965-27.405 MHz
Modulations
AM   FM   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
26.965-27.405 MHz
Modulations
AM   FM   SSB
RF-output
AM/FM: 4 W, SSB: 12 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
154 × 52 × 194 mm (6.06 × 2.05 × 7.64 in)
Weight
1.20 kg (2.6 lbs)
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Citizen Band (27Mc)
Features + options
-
Accessories
-
RigReference ID
5299
MPN
DRAGON-SS-000485
