The Heathkit HX-20 is a transmitter covering 80-10 meters with an RF output of 50 W. Dimensions are 160 × 310 × 235 mm.
General characteristics
- HAM bands
- 80m 40m 20m 15m 10m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- ?
Transmitter
- TX-range
- 80-10 m
- Modulations
- CW SSB
- RF-output
- 50 W
Connections
- Antenna
- BNC
- Impedance
- 50/75Ω
- Other
- -
Electrical
- Power requirements
- Mains
- Current drain RX
- -
- TX
- ?
Physical
- Dimensions (w×h×d)
- 310 × 160 × 235 mm (12.20 × 6.30 × 9.25 in)
- Weight
- ?
- Form factor
- Base Station
- Manufactured
- Between 19xx and 19xx in USA
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 5349
- MPN
- HEATHKIT-HX-000020
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Heathkit HX-20. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the Heathkit HX-20 in Good condition is around:
- USD 127
These estimates are based on the following prices:
