Heathkit EK-2B

General characteristics

HAM bands

?

Frequency stability

?

Tuning steps

?

Memories

?

Receiver

RX-range

540-1600 kHz / 3-10 MHz

Modulations

AM

Sensitivity

20 mV (10 dB S/N)

Selectivity

8 kHz (-6 dB)

Filters

?

Receiver system

Single conversion

IF-frequencies

455 kHz

Image rejection

?

Audio output

?

Connections

Antenna

Clamps / screws

Impedance

50 Ω

Other

-

Electrical

Power requirements

Mains (105-125 V AC)

Current drain RX

40 W

TX

-

Physical

Dimensions (w×h×d)

292 × 165 × 190 mm (11.50 × 6.50 × 7.48 in)

Weight

1.80 kg (4.0 lbs)

Form factor

Base Station

Manufactured

Between 1961 and 196x in USA

Other features

Usage

Amateur / Ham radio operators

Features + options

-

Accessories

-

RigReference ID

5428

MPN

HEATHKIT-EK-000002B

Manuals, diagrams and brochures

No documents available for this particular model.



Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Heathkit EK-2B. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on similar Receiver equipment, the estimated value of the Heathkit EK-2B is around:

• USD 159 ~ USD 295

This estimate is based on similar equipment and may not reflect the exact value of this model.

These estimates are based on the following prices:
