The Ten-Tec 539 is a 160-10 meters transceiver (except 60 and 12 meters) supporting AM/SSB/CW modulations. RF output is 1 - 10 W. Features include DSP, noise reduction, noise blanker, AGC, RIT/XIT, and two VFO displays. The radio has 1 memory bank with 100 channels. Audio output is 1.3 Watts into 8 ohm. Dimensions are 57 × 165 × 193 mm. Current drain is 550 mA in receive mode and 3 A max in transmit mode.
General characteristics
- HAM bands
- 160m 80m 40m 20m 15m 10m
- Frequency stability
- +/- 0.5 p.p.m. over operating temperature
- Tuning steps
- 10, 100, 1000 Hz, speed sensitive, VFO Lock
- Memories
- 100 channels in 1 bank(s)
Receiver
- RX-range
- 160-10 m except 60 and 12 m
- Modulations
- AM CW USB LSB FSK AFSK
- Sensitivity
- Typical receiver sensitivity: < 1 µV
SSB Better than 0.7uv (0.5 µV Typ), 2.4 kHz, 10 dB SINAD
AM : Better than 4 µV, (2.0 µV Typ) 30% Mod, 6 kHz BW, 10 dB SINAD - Selectivity
- ?
- Filters
- 100 built-in DSP filters from 100 – 6000 Hz BW Standard 2.5 kHz roofing filter included
- Receiver system
- DSP (Digital Signal Processing)
- IF-frequencies
- 1st: 9.0018 MHz
2nd: 22.2 kHz
3rd: 0 Hz (DSP) - Image rejection
- 74 dB typical
- Audio output
- 1.3 Watts into 8 ohm, <3% THD
Transmitter
- TX-range
- 160-10 m except 60 and 12 m
- Modulations
- AM CW USB LSB FSK AFSK
- RF-output
- 1 - 10 W
Connections
- Antenna
- SO-239
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 9.5-14 V DC
- Current drain RX
- 550 mA
- TX
- 3 A max
Physical
- Dimensions (w×h×d)
- 165 × 57 × 193 mm (6.50 × 2.24 × 7.60 in)
- Weight
- 1.63 kg (3.6 lbs)
- Form factor
- Mobile
- Manufactured
- Between 2011 and 20xx
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Tri-color display
DSP
Noise Reduction / Noise Blanker
AGC
RIT / XIT
2 VFO displays - Accessories
- -
- RigReference ID
- 5534
- MPN
- TEN-TEC-000539
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Ten-Tec 539. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on similar Transceiver equipment, the estimated value of the Ten-Tec 539 is around:
- USD 219 ~ USD 406
This estimate is based on similar equipment and may not reflect the exact value of this model.
