Military R209

Mobile Shortwave receiver

Specs Manuals (0) Reviews (0) Prices (1) Compare

Find Military R209 rigs and spare parts on eBay

The Military R209 is a mobile shortwave receiver covering 1-20 MHz in 5 bands. It features a superhet receiver system with an IF frequency of 460 kHz and has an audio output of 0.05 W. The receiver weighs 10.5 kg and its dimensions are 215 × 310 × 230 mm. It can be powered by either 12 / 24 V DC or 110 / 120 V AC depending on the version.

General characteristics

HAM bands: ?
Frequency stability: ?
Tuning steps: ?
Memories: ?

Receiver

RX-range: 1-20 MHz in 5 bands
Modulations: AM FM CW
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: Superhet with RF-stage
IF-frequencies: 460 kHz
Image rejection: ?
Audio output: 0.05 W

Connections

Antenna: Proprietary (military)
Impedance: 50Ω
Other: -

Electrical

Power requirements: 12 / 24 V DC, 110 / 120 V AC depending on version
Current drain RX: ?
TX: -

Physical

Dimensions (w×h×d): 310 × 215 × 230 mm (12.20 × 8.46 × 9.06 in)
Weight: 10.50 kg (23.2 lbs)
Form factor: Mobile
Manufactured: Between 1951 and 197x

Other features

Usage: Military communication
Features + options: -
Accessories: -
RigReference ID: 5544
MPN: MILITARY-R000209

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: No documents available for this particular model.

: Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Military R209. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Military R209 is around:

EUR 5.00

Price History Chart

These estimates are based on the following prices:

Year	Historic price	Condition	Submitted by
2010	EUR 40.00	Used / Okay	elmer
