Price when new in 2013: USD 410.

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
100 channels in 1 bank(s)

Receiver

RX-range
0.5-30 MHz
Modulations
AM   CW   USB   LSB   RTTY
Sensitivity
SSB/CW/RTTY
0.5-1.6 MHz: 1 µV
1.6-30 MHz: 0.5 µV
AM
0.5-1.6 MHz: 10 µV
1.6-30 MHz: 2 µV
Selectivity
SSB/CW/RTTY
2.1 kHz @ -6 dB
4.5 kHz @ -60 dB
AM
6 kHz @ -6 dB
20 kHz @ -60 dB
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
2 W into 8 Ohms with 10% THD

Transmitter

TX-range
1.6-30 MHz
Modulations
AM   CW   USB   LSB   RTTY
RF-output
SSB: 100 W, AM: 40 W

Connections

Antenna
-
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
1.4 A
TX
25 A

Physical

Dimensions (w×h×d)
240 × 200 × 65 mm (9.45 × 7.87 × 2.56 in)
Weight
4.00 kg (8.8 lbs)
Form factor
Mobile
Manufactured
Between 20xx and 20xx in China

Other features

Usage
Marine / Navy
Features + options
-
Accessories
-
RigReference ID
5968
MPN
FEITONG-FT-000808
