The Regency HR-2B is a 2 meter transceiver. It covers 144-148 MHz for both receive and transmit frequencies. The receiver system is double conversion superheterodyne with IF frequencies of 10.7 MHz / 455 kHz. RF output is 15 W. It features 1 memory bank with 12 channels. Power requirements are 13.6 V DC. Current drain is 180-800 mA in receive and 2.9 A in transmit. Dimensions are 140 × 64 × 190 mm.
General characteristics
- HAM bands
- 2m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- 12 channels in 1 bank(s)
Receiver
- RX-range
- 144-148 MHz
- Modulations
- FM
- Sensitivity
- 0.35 µV
- Selectivity
- 16 kHz @ -6 dB
32 kHz @ -50 dB - Filters
- ?
- Receiver system
- Double conversion superheterodyne
- IF-frequencies
- 10.7 MHz / 455 kHz
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 144-148 MHz
- Modulations
- FM
- RF-output
- 15 W
Connections
- Antenna
- -
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.6 V DC
- Current drain RX
- 180-800 mA
- TX
- 2.9 A
Physical
- Dimensions (w×h×d)
- 64 × 140 × 190 mm (2.52 × 5.51 × 7.48 in)
- Weight
- ?
- Form factor
- Mobile
- Manufactured
- Between 197x and 197x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 5976
- MPN
- REGENCY-HR-000002B
Manuals, diagrams and brochures
- Regency HR-2B magazine ad JPEG - 640.4 kB, submitted by Pancho Cheja
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Regency HR-2B. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the Regency HR-2B is around:
- USD 10.00
These estimates are based on the following prices:
