Semcoset Semco-Roto S

General characteristics

HAM bands

2m

Frequency stability

?

Tuning steps

Continuous

Memories

None

Receiver

RX-range

144-146 MHz

Modulations

AM   FM   CW   SSB

Sensitivity

?

Selectivity

SSB
2.4 kHz @ -3 dB
4.5 kHz @ -60 dB

AM/FM
12 kHz @ -3 dB
32 kHz @ -60 dB

Filters

?

Receiver system

?

IF-frequencies

?

Image rejection

≥ 60 dB

Audio output

?

Transmitter

TX-range

144-146 MHz

Modulations

AM   FM   CW   SSB

RF-output

10 W

Connections

Antenna

BNC

Impedance

50Ω

Other

-

Electrical

Power requirements

13.5 (11...16) V DC

Current drain RX

600 mA

TX

2.8 A max

Physical

Dimensions (w×h×d)

193 × 88 × 260 mm (7.60 × 3.46 × 10.24 in)

Weight

2.90 kg (6.4 lbs)

Form factor

Mobile

Manufactured

Between 197x and 197x in W.Germany

Other features

Usage

Amateur / Ham radio operators

Features + options

-

Accessories

-

RigReference ID

6125

MPN

SEMCOSET-SEMCO-ROTO-S

Manuals, diagrams and brochures

Semcoset Semco Roto-S User Manual (German) PDF - Unknown size, submitted by RigReference



Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Semcoset Semco-Roto S. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Semcoset Semco-Roto S in Good condition is around:

• EUR 842
