The Semcoset Selecto is a desktop VHF transceiver. It covers 144-146 MHz for both receive and transmit. The rig has an image rejection of 70 dB and frequency stability of ± 300 Hz / hour after warm-up. RF output is SSB: 25 W PEP, FM: 15...25 W, AM: 25 W PEP. It requires 12 V DC power with a current drain of 2 A in receive and 9 A in transmit. Dimensions are 105 × 256 × 273 mm. The transceiver weighs 5.5 kg.
General characteristics
- HAM bands
- 2m
- Frequency stability
- ± 300 Hz / hour after warm-up
- Tuning steps
- Continuous
- Memories
- ?
Receiver
- RX-range
- 144-146 MHz
- Modulations
- AM FM CW SSB
- Sensitivity
- ?
- Selectivity
- SSB
2.4 kHz @ -3 dB, 4.5 kHz @ -60 dB
AM/FM
15 kHz @ -3 dB, 32 kHz @ -60 dB - Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- 70 dB
- Audio output
- ?
Transmitter
- TX-range
- 144-146 MHz
- Modulations
- AM FM CW SSB
- RF-output
- SSB: 25 W PEP, FM: 15...25 W, AM: 25 W PEP
Connections
- Antenna
- SO-239
- Impedance
- 60Ω
- Other
- -
Electrical
- Power requirements
- 12 V DC
- Current drain RX
- 2 A
- TX
- 9 A
Physical
- Dimensions (w×h×d)
- 256 × 105 × 273 mm (10.08 × 4.13 × 10.75 in)
- Weight
- 5.50 kg (12.1 lbs)
- Form factor
- Base Station
- Manufactured
- Between 19xx and 19xx in West-Germany
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 6189
- MPN
- SEMCOSET-SELECTO
Manuals, diagrams and brochures
- Semco Selecto User manual PDF - 4.11 MB, submitted by RigReference
- Upload relevant documents
