The Youkits TJ6A Pro is a 6 band SSB/CW transceiver. The frequency range for reception is 2.5-4.1 / 5-8 / 10-15.1 / 18-22 MHz and the frequency range for transmission is 1.5-4 / 7-7.5 / 10.1-10.15 / 14-14.5 / 18.068-18.168 / 21-21.5 MHz. Frequency stability is 0.6 µV (10 dB S/N). The receiver system is single conversion superheterodyne with an IF frequency of 9 MHz. RF output is 5-8 W. The transceiver features a signal strength meter, 1 memory bank with 8 channels and requires 13.8 V DC power. Current drain in receive mode is 180 mA.
General characteristics
- HAM bands
- 80m 60m 40m 30m (WARC) 20m 17m (WARC) 15m
- Frequency stability
- 0.6 µV (10 dB S/N)
- Tuning steps
- ?
- Memories
- 8 channels in 1 bank(s)
Receiver
- RX-range
- 2.5-4.1 / 5-8 / 10-15.1 / 18-22 MHz
- Modulations
- CW USB LSB
- Sensitivity
- 0.3 µV
- Selectivity
- ?
- Filters
- ?
- Receiver system
- Single conversion superheterodyne
- IF-frequencies
- 9 MHz
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 1.5-4 / 7-7.5 / 10.1-10.15 / 14-14.5 / 18.068-18.168 / 21-21.5 MHz
- Modulations
- CW USB LSB
- RF-output
- 5-8 W
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 13.8 V DC
- Current drain RX
- 180 mA
- TX
- ?
Physical
- Dimensions (w×h×d)
- ?
- Weight
- ?
- Form factor
- Kit
- Manufactured
- Between 20xx and 20xx in Canada
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Signal strength meter
- Accessories
- -
- RigReference ID
- 6237
- MPN
- YOUKITS-TJ000006A-PRO
