The Youkits SK-1A is a 40m SSB transceiver. Frequency range is 5.9-8 MHz for reception and 7.0-7.3 MHz for transmission. Frequency stability is ~100 Hz per half hour. Tuning steps are 10 / 100 Hz, 1 / 100 kHz. RF output is 8-9 W (@ 13.8 V DC). Memory banks: 1 with 8 memory channels. Power requirements are 10-15 V DC. Features include Sidetone: 700 Hz and Keyer: 5-40 wpm adjustable. Dimensions are 38 × 88 × 124 mm. Current drain is 50-60 mA (RX) and 800 mA (TX).
General characteristics
- HAM bands
- 40m
- Frequency stability
- ~ 100 Hz per half hour
- Tuning steps
- 10 / 100 Hz, 1 / 100 kHz
- Memories
- 8 channels in 1 bank(s)
Receiver
- RX-range
- 5.9-8 MHz
- Modulations
- CW SSB
- Sensitivity
- ?
- Selectivity
- 4 crystal filter, 400Hz-3KHz continued adjustable
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- 400 Hz - 3 kHz
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 7.0-7.3 MHz
- Modulations
- CW SSB
- RF-output
- 8-9 W (@ 13.8 V DC)
Connections
- Antenna
- BNC
- Impedance
- ?
- Other
- -
Electrical
- Power requirements
- 10-15 V DC
- Current drain RX
- 50-60 mA
- TX
- 800 mA
Physical
- Dimensions (w×h×d)
- 88 × 38 × 124 mm (3.46 × 1.50 × 4.88 in)
- Weight
- 280 gr (9.9 oz)
- Form factor
- Handheld
- Manufactured
- Between 201x and 201x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Sidetone: 700 Hz
Keyer: 5-40 wpm adjustable - Accessories
- -
- RigReference ID
- 6245
- MPN
- YOUKITS-SK-000001A
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Youkits SK-1A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the Youkits SK-1A is around:
- USD 121.00 ~ USD 114.00
