The Heathkit HM-11 is a base station HF power/SWR meter. It covers 160-6 MHz for both transmit and receive. The maximum RF output is 1 kW. Dimensions are 121 × 184 × 108 mm. It weighs 1.4 kg.
General characteristics
- HAM bands
- 160m 80m 60m 40m 30m (WARC) 20m 17m (WARC) 15m 12m (WARC) 11m (CB) 10m
- Frequency stability
- -
- Tuning steps
- -
- Memories
- None
Frequency range
- Range
- 160-6 MHz
Connections
- Antenna
- SO-239
- Impedance
- 50/75Ω
- Other
- -
Electrical
- Power requirements
- None
- Current drain RX
- -
- TX
- -
Physical
- Dimensions (w×h×d)
- 184 × 121 × 108 mm (7.24 × 4.76 × 4.25 in)
- Weight
- 1.40 kg (3.1 lbs)
- Form factor
- Base Station
- Manufactured
- Between 1962 and 1965 in USA
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 6591
- MPN
- HEATHKIT-HM-000011
Manuals, diagrams and brochures
- Heathkit HM-11 Assembly and Operation Manual PDF - 2.31 MB, submitted by Wim
- Upload relevant documents
