President PM 1200 WP

Handheld Marine Transceiver

Specs Manuals (1) Reviews (0) Prices (0) Compare

Find President PM 1200 WP rigs and spare parts on eBay

Find the President PM 1200 WP on Amazon

The President PM 1200 WP is a handheld marine transceiver. It covers 156.050-162.025 MHz for both receive and transmit. Frequency stability is ± 10 p.p.m. with channelized tuning steps. RF output is selectable between 1/4 W and 4 W. Audio output is 1 W. The radio features 1 memory bank with 24 channels. It operates on 7.2 V DC, 1350 mAh Nio-MH battery. Dimensions are 143 × 65 × 40 mm. Current drain in receive mode is 60-180 mA and 600-1200 mA in transmit mode. The transceiver weighs 320 gr.

General characteristics

HAM bands: None
Frequency stability: ± 10 p.p.m.
Tuning steps: Channelized
Memories: 24 channels in 1 bank(s)

Receiver

RX-range: 156.050-162.025 MHz
Modulations: FM
Sensitivity: -3 dB µV (20 dB SINAD)
Selectivity: ?
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: ?
Audio output: 1 W

Transmitter

TX-range: 156.050-162.025 MHz
Modulations: FM
RF-output: 1 / 4 W

Connections

Antenna: SMA
Impedance: ?
Other: -

Electrical

Power requirements: 7.2 V DC, 1350 mAh Nio-MH
Current drain RX: 60-180 mA
TX: 600-1200 mA

Physical

Dimensions (w×h×d): 65 × 143 × 40 mm (2.56 × 5.63 × 1.57 in)
Weight: 320 gr (11.3 oz)
Form factor: Handheld
Manufactured: Between 20xx and 20xx

Other features

Usage: Marine / Navy
Features + options: -
Accessories: -
RigReference ID: 6600
MPN: PRESIDENT-PM-001200-WP

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: Manual President PM-1200 WP PDF - 376.3 kB, submitted by Gerd

: Upload relevant documents
