Yaesu FTM-510 ASP
Amateur Base Station Antenna
Add a review (+10 rep) Own this rig? Add it to your shack
General characteristics
- HAM bands
- 2m 70cm
- Frequency stability
- ±2.5 p.p.m. @ -20 to +60°C (-4 to +140°F)
- Tuning steps
- 5 / 6.25 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 kHz
- Memories
- 1053 channels in 1 bank(s)
Receiver
- RX-range
- 108-550 MHz
- Modulations
- FM N-FM C4FM
- Sensitivity
- AM (10 dB S/N)
108-137 MHz: 0.8 µV
300-336 MHz: 0.8 µV
FM (12 dB SINAD)
137-150 MHz: 0.2 µV
150-174 MHz: 0.25 µV
174-222 MHz: 0.3 µV
222-300 MHz: 0.25 µV
336-420 MHz: 0.25 µV
420-470 MHz: 0.2 µV
470-550 MHz: 0.2 µV
DV/Fusion (BER 1%)
2 m/70 cm: 0.19 µV - Selectivity
- 12 kHz (-6 dB)
30 kHz (-60 dB) - Filters
- ?
- Receiver system
- Double conversion superheterodyne
- IF-frequencies
- 1st: 56.75 MHz (Main RX) - 55.85 MHz (Sub RX)
2nd: 450 kHz - Image rejection
- ?
- Audio output
- 3 W (Main unit), 6 W (Control head) at 10% distortion / 8 ohm
Transmitter
- TX-range
- 144-146 / 430-440 MHz (Europe)
144-148 / 430-450 MHz (USA) - Modulations
- FM N-FM C4FM
- RF-output
- 5 / 25 / 55 W
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 11.7-15.8 V DC
- Current drain RX
- 500 mA
- TX
- 11 A
Physical
- Dimensions (w×h×d)
- 156 × 64 × 59 mm (6.14 × 2.52 × 2.32 in) Control unit
- Weight
- 1.40 kg (3.1 lbs)
- Form factor
- Base Station
- Manufactured
- Between 2025 and 20xx in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 6639
- MPN
- YAESU-FTM-000510-ASP
